Optional Accessories ED12-321A
252 Options
1. Optional Accessories
1.1 Option List
1.1.1 Indoor Units
Wall Mounted Type
★
1 Wiring adaptor is also required for each indoor unit.
★
2 Wiring adaptor ; supplied by DAIKIN. Time clock and other devices ; field supply.
Duct Connected Type
★
1 Wiring adaptor is also required for each indoor unit.
★
2 Wiring adaptor ; supplied by DAIKIN. Time clock and other devices ; field supply.
Floor / Ceiling Suspended Dual Type
★
1 Wiring adaptor is also required for each indoor unit.
★
2 Wiring adaptor ; supplied by DAIKIN. Time clock and other devices ; field supply.
Option Name FTK(X)E25/35BVMA FTK(X)D50/60/71BVMA
1 Centralized Control Board-up to 5 Rooms
★
1
KRC72
2
Wiring Adaptor for Time Clock/Remote Control
★
2
(Normal Open Pulse Contact / Normal Open Contact)
KRP413A1S
3 Central Remote Controller
★
1
DCS302B61
4 Unified ON/OFF Controller
★
1
DCS301B61
5 Schedule Timer
★
1
DST301B61
6 Interface Adaptor for Room Air Conditioner
★
2
KRP928A2S
7 Photocatalytic Deodorizing Filter with Frame KAZ917B41 —
8 Photocatalytic Deodorizing Filter without Frame KAZ917B42 —
9 Air Purifying Filter with Frame KAF925B41 —
10 Air Purifying Filter without Frame KAF925B42 —
11
Air Purifying Filter with Photocatalytic Deodorizing
Function
— KAF952A42
12 Remote Controller Loss Prevention with the Chain KKF917A4
Option Name CDK(X)25/35/50/60AVMA
1 Centralized Control Board-up to 5 Rooms
★
1
KRC72
2
Wiring Adaptor for Time Clock/Remote Control
★
2
(Normal Open Pulse Contact / Normal Open Contact)
KRP413A1S
3 Central Remote Controller
★
1
DCS302B61
4 Unified ON/OFF Controller
★
1
DCS301B61
5 Schedule Timer
★
1
DST301B61
6 Interface Adaptor for Room Air Conditioner
★
2
KRP928A2S
7 Suction Grille KDGF19A45
8 Remote Controller Loss Prevention with the Chain KKF917A4
Option Name FLK(X)25/35/50/60AVMA
1 Centralized Control Board-up to 5 Rooms
★
1
KRC72
2
Wiring Adaptor for Time Clock/Remote Control
★
2
(Normal Open Pulse Contact / Normal Open Contact)
KRP413A1S
3 Central Remote Controller
★
1
DCS302B61
4 Unified ON/OFF Controller
★
1
DCS301B61
5 Schedule Timer
★
1
DST301B61
6 Interface Adaptor for Room Air Conditioner
★
2
KRP928A2S
7 Photocatalytic Deodorizing Filter with Frame KAZ917B41
8 Photocatalytic Deodorizing Filter without Frame KAZ917B42
9 Air Purifying Filter with Frame KAF925B41
10 Air Purifying Filter without Frame KAF925B42
11 Remote Controller Loss Prevention with the Chain KKF917A4
