Outdoor Units ED12-321A
186 Installation Manual
Installation
Connections (connection port)
Refer to “How to Use Reducers” for information on reducer numbers and their shapes.
: Use a reducer to connect pipes.
: Use No. 2 and 5 reducers
: Use No. 7 and 8 reducers
: Use No. 1 and 4 reducers
: Use No. 3 and 6 reducers
#
▲
■
●
Port
A
B
C
D
4MXD80∗
25
25 , 35
25 , 35 , 50 , 60
25 , 35 , 50 , 60 , 71
▲ ■ ■
#
▲
●
■
●
■
●●
4MKD90∗
25 , 35
25 , 35 , 50 , 60
25 , 35 , 50 , 60 , 71
25 , 35 , 50 , 60 , 71
▲
●
■
●
■
●●
▲
●
■
●
■
●●
▲ ■ ■
#
● Install the unit horizontally.
● The unit may be installed directly on a concrete verandah or a solid place if drainage is good.
● If the vibration may possibly be transmitted to the building, use a vibration-proof rubber (field supply).
Install the indoor unit according to the table below, which shows the relationship between the class of indoor unit and the
corresponding port.
The total indoor unit class that can be connected to this unit:
Heat pump type: 4MXD80∗ – Up to 13.5kW
Cooling only type: 4MKD90∗ – Up to 15.5kW
