ED12-321A Capacity Tables
SUPER MULTI NX B-Series Cooling Only 39
2
3D042745#4
3D042745#5
3D042745#6
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
2.5+3.5+7.1 22 8.35 2.11 8.87 2.35 9.38 2.39 9.64 2.41 10.41 2.45 10.92 2.47
25 8.04 2.49 8.55 2.54 9.07 2.58 9.32 2.59 10.09 2.65 10.61 2.68
32 7.60 2.75 8.12 2.82 8.63 2.88 8.89 2.91 9.66 2.99 10.17 3.05
35 7.42 2.88 7.93 2.96 8.44 3.03
8.70 3.07 9.47 3.15 9.98 3.21
40 7.10 3.11 7.62 3.21 8.13 3.30 8.39 3.34 9.16 3.45 9.67 3.52
43 6.92 3.27 7.43 3.36 7.94 3.46 8.20 3.51 8.97 3.64 9.47 3.67
46 6.70 3.18 7.16 3.18 7.63 3.18 7.84 3.18 8.50 3.18 8.95 3.18
2.5+5.0+5.0 22 8.26 1.93 8.76 2.15 9.27 2.18 9.53 2.20 10.29 2.24 10.79 2.26
25 7.95 2.27 8.46 2.31 8.96 2.35 9.22 2.37 9.98 2.41 10.49 2.44
32 7.52 2.51 8.02 2.58 8.53 2.63 8.79 2.66 9.55 2.73 10.05 2.78
35 7.33 2.63 7.84 2.70 8.35 2.77
8.60 2.80 9.36 2.88 9.87 2.92
40 7.02 2.83 7.53 2.92 8.04 3.01 8.29 3.04 9.05 3.15 9.56 3.21
43 6.84 2.98 7.34 3.06 7.85 3.15 8.11 3.20 8.87 3.32 9.38 3.38
46 6.65 3.12 7.14 3.18 7.61 3.18 7.83 3.18 8.49 3.18 8.91 3.18
2.5+5.0+6.0 22 8.40 2.00 8.92 2.22 9.43 2.26 9.69 2.27 10.47 2.32 10.98 2.34
25 8.09 2.35 8.60 2.40 9.12 2.43 9.38 2.45 10.15 2.50 10.67 2.53
32 7.65 2.60 8.16 2.67 8.68 2.72 8.94 2.75 9.71 2.82 10.23 2.88
35 7.46 2.72 7.98 2.79 8.49 2.87
8.75 2.90 9.52 2.98 10.04 3.03
40 7.14 2.93 7.66 3.03 8.18 3.11 8.44 3.15 9.21 3.26 9.73 3.32
43 6.96 3.09 7.47 3.17 7.99 3.27 8.25 3.31 9.02 3.43 9.54 3.50
46 6.76 3.18 7.23 3.18 7.70 3.18 7.93 3.18 8.59 3.18 9.02 3.18
3.5+3.5+3.5 22 7.92 2.02 8.41 2.25 8.89 2.28 9.14 2.30 9.87 2.34 10.36 2.36
25 7.62 2.38 8.11 2.42 8.60 2.46 8.84 2.48 9.57 2.53 10.06 2.56
32 7.21 2.63 7.70 2.70 8.18 2.75 8.43 2.78 9.16 2.85 9.65 2.91
35 7.03 2.75 7.52 2.82 8.01 2.90
8.25 2.93 8.98 3.01 9.47 3.06
40 6.74 2.96 7.22 3.06 7.71 3.15 7.95 3.19 8.68 3.29 9.17 3.36
43 6.56 3.12 7.05 3.21 7.53 3.30 7.78 3.35 8.51 3.47 8.99 3.54
46 6.38 3.18 6.84 3.18 7.30 3.18 7.51 3.18 8.15 3.18 8.56 3.18
3.5+3.5+5.0 22 8.17 2.04 8.67 2.27 9.17 2.31 9.43 2.32 10.18 2.36 10.68 2.39
25 7.86 2.40 8.37 2.45 8.87 2.48 9.12 2.50 9.87 2.55 10.38 2.58
32 7.44 2.66 7.94 2.72 8.44 2.78 8.69 2.81 9.45 2.88 9.95 2.94
35 7.25 2.78 7.76 2.85 8.26 2.93
8.51 2.96 9.26 3.04 9.77 3.09
40 6.95 2.99 7.45 3.09 7.95 3.18 8.20 3.22 8.96 3.33 9.46 3.39
43 6.77 3.15 7.27 3.24 7.77 3.33 8.02 3.38 8.78 3.51 9.28 3.58
46 6.57 3.18 7.04 3.18 7.50 3.18 7.73 3.18 8.37 3.18 8.79 3.18
3.5+3.5+6.0 22 8.30 2.11 8.82 2.35 9.33 2.39 9.58 2.41 10.35 2.45 10.86 2.47
25 7.99 2.49 8.50 2.54 9.02 2.58 9.27 2.59 10.04 2.65 10.55 2.68
32 7.56 2.75 8.07 2.82 8.58 2.88 8.84 2.91 9.60 2.99 10.11 3.05
35 7.37 2.88 7.88 2.96 8.39 3.03
8.65 3.07 9.42 3.15 9.93 3.21
40 7.06 3.11 7.57 3.21 8.08 3.30 8.34 3.34 9.11 3.45 9.62 3.52
43 6.88 3.27 7.39 3.36 7.90 3.46 8.15 3.51 8.92 3.64 9.42 3.67
46 6.66 3.18 7.12 3.18 7.58 3.18 7.80 3.18 8.45 3.18 8.89 3.18
3.5+5.0+5.0 22 8.40 1.96 8.92 2.18 9.43 2.22 9.69 2.23 10.47 2.28 10.98 2.30
25 8.09 2.31 8.60 2.36 9.12 2.39 9.38 2.41 10.15 2.46 10.67 2.49
32 7.65 2.56 8.16 2.62 8.68 2.68 8.94 2.70 9.71 2.77 10.23 2.83
35 7.46 2.68 7.98 2.74 8.49 2.82
8.75 2.85 9.52 2.93 10.04 2.98
40 7.14 2.88 7.66 2.98 8.18 3.06 8.44 3.10 9.21 3.20 9.73 3.26
43 6.96 3.04 7.47 3.12 7.99 3.21 8.25 3.26 9.02 3.38 9.54 3.44
46 6.77 3.17 7.24 3.18 7.71 3.18 7.94 3.18 8.60 3.18 9.03 3.18
Symbols NOTE:
TC : Total capacity (kW)
Capacities are based on the following conditions.
Corresponding refrigerant piping length : 7.5m
Level difference : 0m
PI : Power input (kW)
