Specifications Si18-201
24 Specifications
"
Floor/Ceiling Suspended Dual Type
★
Refer to Engineering Data Book.
"
2.5kW Class
50Hz 220-230-240V / 60Hz 220-230V
Model FLK25HVE FLK25HVEA
Rating Capacity kW 2.5
Front Panel Color Almond White
Air Flow Rates
m³/min
H7.6
M6.8
L6.0
cfm
H268
M240
L212
Fan
Type Sirocco Fan
Motor Output W 34
Speed Steps 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.32 - 0.32 - 0.32 / 0.34 - 0.34
Power Consumption
★
(Rated) W 68 - 70 - 72 / 72 - 74
Power Factor
★
% 96.6 - 95.1 - 93.8 / 95.1 - 94.6
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200
Package Dimensions mm 1,100×566×284
Weight kg 16
Gross Weight kg 22
Operation Sound dBA
H37
M34
L31
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
9.5
Drain mm
φ
18.0
Drawing No. 3D024997 3D025009
"
3.5kW Class
50Hz 220-230-240V / 60Hz 220-230V
Model FLK35HVE FLK35HVEA
Rating Capacity kW 3.5
Front Panel Color Almond White
Air Flow Rates
m³/min
H8.7
M7.7
L6.6
cfm
H 307
M 270
L 233
Fan
Type Sirocco Fan
Motor Output W 34
Speed Steps 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.36 - 0.36 - 0.36 / 0.39 - 0.39
Power Consumption
★
(Rated) W 76 - 78 - 80 / 80 - 84
Power Factor
★
% 96.0 - 94.2 - 92.6 / 94.0 - 93.6
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200
Package Dimensions mm 1,100×566×284
Weight kg 16
Gross Weight kg 22
Operation Sound dBA
H38
M35
L32
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
12.7
Drain mm
φ
18.0
Drawing No. 3D024998 3D025010
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
