Si18-201 Specifications
Specifications 25
★
Refer to Engineering Data Book.
"
5.0kW Class
50Hz 220-230-240V / 60Hz 220-230V
Model FLK50HVE FLK50JVEA9
Rating Capacity kW 5.0
Front Panel Color Almond White
Air Flow Rates
m³/min
H 11.4 11.4
M 10.0 9.9
L8.5 8.5
cfm
H 402 402
M 351 349
L 300 300
Fan
Type Sirocco Fan
Motor Output W 34
Speed Steps 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.45 - 0.45 - 0.45 / 0.48 - 0.48
Power Consumption
★
(Rated) W 94 - 96 - 98 / 98 - 101
Power Factor
★
% 94.2 - 92.8 - 90.7 / 92.1 - 91.5
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200
Package Dimensions mm 1,100×566×284
Weight kg 17
Gross Weight kg 24
Operation Sound dBA
H47
M43
L39
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
12.7
Drain mm
φ
18.0
Drawing No. 3D024999 3D027868C
"
6.0kW Class
50Hz 220-230-240V / 60Hz 220-230V
Model FLK60HVE FLK60JVEA
Rating Capacity kW 5.7
Front Panel Color Almond White
Air Flow Rates
m³/min
H 12.0 12.0
M 10.7 10.6
L9.3 9.3
cfm
H 424 424
M 376 374
L 328 328
Fan
Type Sirocco Fan
Motor Output W 34
Speed Steps 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.47 - 0.47 - 0.47 / 0.51 - 0.51 0.47 - 0.47 - 0.47 / 0.51 - 0.51
Power Consumption
★
(Rated) W 96 - 98 - 100 / 100 - 104 96 - 98 - 100 / 100 - 104
Power Factor
★
% 92.8 - 90.7 - 88.7 / 90.0 - 88.7 92.8 - 90.7 - 88.7 / 89.1 - 88.7
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200
Package Dimensions mm 1,100×566×284
Weight kg 17
Gross Weight kg 24
Operation Sound dBA
H49
M45
L41
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
15.9
Drain mm
φ
18.0
Drawing No. 3D025000 3D027869
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
