Specifications Si18-201
38 Specifications
1.4.2 Heat Pump
"
""
"
Wall Mounted Type
★
Refer to Engineering Data Book.
50Hz 220V
Model
FTX25JVEC FTX35JVEC
Cooling Heating Cooling Heating
Rating Capacity kW 2.5 3.4 3.5 4.2
Front Panel Color Almond White Almond White
Air Flow Rates
m³/min
H 7.5 8.5 7.5 8.7
M 6.4 7.3 6.5 7.5
L 5.4 6.2 5.5 6.2
cfm
H 265 300 265 307
M 226 258 229 265
L 191 219 194 219
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps and Auto 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.17 0.17
Power Consumption
★
(Rated) W 37 37
Power Factor
★
% 98.9 98.9
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 273×784×185
Package Dimensions mm 834×325×258 834×325×258
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation Sound dBA
H39373938
M35343635
L30303231
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D020444A 3D020445A
50Hz 220V
Model
FTX50HVEC FTX60HVEC
Cooling Heating Cooling Heating
Rating Capacity kW 5.0 6.13 6.0 7.32
Front Panel Color Almond White
Air Flow
Rates
m³/min
H 12.9 15.2 14.0 16.3
M 11.2 13.1 12.1 14.0
L 9.4 11.0 10.3 11.7
cfm
H 455 537 494 575
M 395 462 427 494
L 332 388 364 413
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 35 35
Speed Steps 5 Steps and Auto 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.50 0.60
Power Consumption
★
(Rated) W 50 60
Power Factor
★
% ——
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 298×1,050×190 298×1,050×190
Package Dimensions mm 1,183×367×289 1,183×367×289
Weight kg 12 12
Gross Weight kg 16 16
Operation Sound dBA
H44444646
M39384241
L35333834
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D013592 3D013595
