Main Functions Si18-201
80 Main Functions
Flap Angle During Heating
During Cooling
Capable of
sending air to the
center of a room
even if it is
installed at a
corner of the
room.
1.1.3 Horizontal Auto-Swing (Up and Down)
For FTK, FTX50/
60 H Series Only
Auto-swing angles are about “A” degrees when the fan is ON, and about “B” degrees when the
cooling or program dry operation is ON. The up-and-down swing of the flaps widens the
direction of wind.
Blade Angle
