Specifications Si18-201
34 Specifications
1.4 Indoor Units (for China)
1.4.1 Cooling Only
"
Wall Mounted Type
★
Refer to Engineering Data Book.
50Hz 220V
Model FTK25JVEC FTK35JVEC
Rating Capacity kW 2.5 3.5
Front Panel Color Almond White Almond White
Air Flow Rates
m³/min
H7.5 7.5
M6.4 6.5
L5.5 5.5
cfm
H 265 265
M 226 229
L 194 194
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps and Auto 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current
★
★★
★
(Rated) A 0.17 0.17
Power Consumption
★
★★
★
(Rated) W 37 37
Power Factor
★
★★
★
% 98.9 98.9
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 273×784×185
Package Dimensions mm 834×325×258 834×325×258
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation Sound dBA
H39 39
M35 36
L30 32
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D020446A 3D020447A
50Hz 220V
Model FTK50HVEC FTK60HVEC
Rating Capacity kW 5.0 6.0
Front Panel Color Almond White Almond White
Air Flow Rates
m³/min
H 12.9 14.0
M 11.2 12.1
L 9.4 10.3
cfm
H 455 494
M 395 427
L 332 364
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 35 35
Speed Steps 5 Steps and Auto 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.50 0.60
Power Consumption
★
(Rated) W 50 60
Power Factor
★
% ——
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 298×1,050×190 298×1,050×190
Package Dimensions mm 1,183×367×289 1,183×367×289
Weight kg 12 12
Gross Weight kg 16 16
Operation Sound dBA
H44 46
M39 42
L35 38
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D013610 3D013614
