Si18-201 Specifications
Specifications 31
"
Floor / Ceiling Suspended Dual Type
★
Refer to Engineering Data Book.
"
2.5kW Class · 3.5kW Class
50Hz 220-230-240V / 60Hz 220-230V
Model
FLX25HVEA FLX35HVEA
Cooling Heating Cooling Heating
Rating Capacity kW 2.5 3.86 3.5 4.42
Front Panel Color Almond White
Air Flow Rates
m³/min
H 7.6 9.2 8.7 10.0
M 6.8 8.3 7.7 9.0
L 6.0 7.4 6.6 8.0
cfm
H 268 325 307 353
M 240 293 270 318
L 212 261 233 282
Fan
Type Sirocco Fan
Motor Output W 34
Speed Steps 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof
Running Current
★
(Rated) A
0.32 - 0.32 - 0.32
/ 0.34 - 0.34
0.34 - 0.34 - 0.34
/ 0.37 - 0.37
0.36 - 0.36 - 0.36 / 0.39 - 0.39
Power Consumption
★
(Rated) W 68 - 70 - 72 / 72 - 74 72 - 74 - 76 / 76 - 79 76 - 78 - 80 / 80 - 84 76 - 78 - 80 / 80 - 83
Power Factor
★
%
96.6 - 95.1 - 93.8
/ 95.1 - 94.6
96.3 - 94.6 - 93.1
/ 94.5 - 92.8
96.0 - 94.2 - 92.6
/ 94.0 - 93.6
96.0 - 94.2 - 92.6
/ 94.0 - 92.5
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200
Package Dimensions mm 1,100×566×284
Weight kg 16
Gross Weight kg 22
Operation Sound dBA
H37373839
M34343536
L31313233
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D025021 3D025022
"
5.0kW Class · 6.0kW Class
50Hz 220-230-240V / 60Hz 220-230V
Model
FLX50JVEA9 FLX60JVEA
Cooling Heating Cooling Heating
Rating Capacity kW 5.0 6.1 5.7 6.7
Front Panel Color Almond White
Air Flow Rates
m³/min
H 11.4 12.1 12.0 12.8
M 9.9 9.8 10.6 10.6
L 8.5 7.5 9.3 8.4
cfm
H 402 427 424 452
M 349 346 374 374
L 300 265 328 297
Fan
Type Sirocco Fan
Motor Output W 34
Speed Steps 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof
Running Current
★
(Rated) A
0.45 - 0.45 - 0.45
/ 0.48 - 0.48
0.45 - 0.45 - 0.45
/ 0.48 - 0.48
0.47 - 0.47 - 0.47
/ 0.51 - 0.51
0.45 - 0.45 - 0.45
/ 0.48 - 0.48
Power Consumption
★
(Rated) W 94 - 96 - 98 / 98 - 100 94 - 96 - 98 / 98 - 100 96 - 98 - 100 / 100 - 104 94 - 96 - 98 / 98 - 101
Power Factor
★
%
94.2 - 92.8 - 90.7
/ 92.1 - 91.5
94.2 - 92.8 - 90.7
/ 92.1 - 91.5
92.8 - 90.7 - 88.7
/ 89.1 - 88.7
94.9 - 92.8 - 90.7
/ 92.8 - 91.5
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200
Package Dimensions mm 1,100×566×284
Weight kg 17
Gross Weight kg 24
Operation Sound dBA
H47464847
M43414542
L39354137
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D027866B 3D027867A
