Si18-201 Specifications
Specifications 33
"
Duct Connected Type (SkyAir)
★
Refer to Engineering Data Book.
"
6.0kW Class · 7.7kW Class
50Hz 220-230-240V
Model
FDYM60FAV1 FDYM03FAV1
Cooling Heating Cooling Heating
Rating Capacity 6.0 7.0 7.7 7.9
Front Panel Color —
Air Flow
Rates
m³/min
H 20.0
L —
cfm
H 706
L —
Fan
Type Sirocco Fan
Motor Output W 125
Speed Steps 2 Step and Auto
Air Filter —
Running Current
★
(Rated) A 0.9
Power Consumption
★
(Rated) W 170
Power Factor
★
% 85.9
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 295×1,100×680
Package Dimensions mm 349×1,311×864
Weight kg 42
Gross Weight kg 54
Operation Sound dBA
H39
L —
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
9.5
Gas mm
φ
15.9
Drain mm 3/4B
60Hz 220-230V
Model
FDYM60FAVAL FDYM03FAVAL
Cooling Heating Cooling Heating
Rating Capacity 6.0 7.0 7.7 7.9
Front Panel Color —
Air Flow
Rates
m³/min
H20 22
L ——
cfm
H 706 777
L ——
Fan
Type Sirocco Fan
Motor Output W 125
Speed Steps 2 step and Auto
Air Filter —
Running Current
★
(Rated) A —
Power Consumption
★
(Rated) W —
Power Factor
★
% —
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 295×1,100×680
Package Dimensions mm 349×1,311×864
Weight kg 42
Gross Weight kg 54
Operation Sound dBA
H42
L —
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
9.5
Gas mm
φ
15.9
Drain mm 3/4B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
