SiBE05-312 Outdoor Unit
Removal Procedure 129
The front grille has four
claws. Slide the discharge
grille upwards and remove it.
3
Loosen the six screws
of the front panel.
4
Push the front panel
and undo the claw.
Lift the clamp plate and
remove it.
Step
Procedure Points
