Outdoor Unit SiBE05-312
130 Removal Procedure
5
Undo the right side
claw, and then the left
side claws.
Remove the front panel.
Lift the front panel and
remove it while pushing the
right side panel inwards.
Lift the front panel and undo
the left side claws.
Fit the left side of the front
panel first when installing.
Step
Procedure Points
