SiBE07-724_B Outdoor Unit - RK(X)S25/35G2V1B9
Removal Procedure 185
2. Remove the filter PCB.
1
Release the harnesses
from the hook.
2
Cut the clamp.
3
Release the harnesses
from the hook.
Step
Procedure Points
(R11869)
Filter PCB
(R11871)
(R11872)
