Piping Diagrams SiBE07-724_B
208 Appendix
1. Piping Diagrams
1.1 Indoor Unit
FDK(X)S25/35CAVMB, FDK(X)S25/35EAVMB
A
INDOOR UNIT
SIROCCO FAN
(
6.4CuT
)
(
A CuT)
FAN MOTOR
M
HEAT EXCHANGER
FDXS25EAVMB
FDXS35EAVMB
9.5
FDXS25CAVMB
FDXS35CAVMB
FDKS25CAVMB
FDKS35CAVMB
FDKS25EAVMB
FDKS35EAVMB
C: 4D045449L
REFRIGERANT FLOW
COOLING
HEATING
FIELD PIPING
(
6.4CuT
)
FIELD PIPING
(
A CuT)
THERMISTOR
ON HEAT
EXCH.
