Specifications SiBE07-724_B
10 Specifications
50 Hz, 230 V
Note:
The data are based on the conditions shown in the table below.
The operating sound is based on the rear side suction inlet and the external static pressure 40 Pa.
Operating sound for under side suction inlet : [operating sound for rear side suction inlet] + 5 dB.
However, when installation to which the external static pressure becomes low is carried out, 5 dB
or more may go up.
Models
Indoor Units FDKS25CAVMB FDKS35CAVMB
Outdoor Units RKS25G2V1B RKS35G2V1B
Capacity Rated (Min. ~ Max.)
kW 2.4 (1.3 ~ 3.0) 3.4 (1.4 ~ 3.8)
Btu/h 8,150 (4,400 ~ 10,200) 11,600 (4,800 ~ 13,000)
kcal/h 2,060 (1,110 ~ 2,580) 2,920 (1,200 ~ 3,260)
Moisture Removal L/h 1.2 1.9
Running Current (Rated) A 4.0 5.0
Power Consumption
Rated (Min. ~ Max.)
W 690 1,090
Power Factor % 75.4 95.0
COP (Rated) W/W 3.48 3.12
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm VP20 (O.D.
φ
26 / I.D.
φ
20) VP20 (O.D.
φ
26 / I.D.
φ
20)
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Units FDKS25CAVMB FDKS35CAVMB
External Static Pressure Pa 40 40
Airflow Rate
m³/min
(cfm)
H 9.5 (335) 10.0 (353)
M 8.8 (311) 9.3 (328)
L 8.0 (282) 8.5 (300)
SL 6.7 (237) 7.0 (247)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 62 62
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control – –
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.47 0.47
Power Consumption (Rated) W 100 100
Power Factor % 92.5 92.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 200 × 900 × 620 200 × 900 × 620
Packaged Dimensions (H × W × D) mm 266 × 1,106 × 751 266 × 1,106 × 751
Weight kg 25 25
Gross Weight kg 31 31
Operation
Sound
H / M / L / SL dBA 35 / 33 / 31 / 29 35 / 33 / 31 / 29
Sound Power dBA 53 53
Outdoor Units RKS25G2V1B RKS35G2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AFXD 1YC23AFXD
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 1.00 1.20
Airflow Rate
m³/min
(cfm)
H 33.5 (1,183) 36.0 (1,272)
SL 31.4 (1,109) 31.4 (1,109)
Fan
Type Propeller Propeller
Motor Output W 50 50
Running Current (Rated) A 2.93 4.08
Power Consumption (Rated) W 532 844
Power Factor % 78.9 89.9
Starting Current A 3.2 4.4
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 612 × 906 × 364 612 × 906 × 364
Weight kg 34 34
Gross Weight kg 40 40
Operation
Sound
H / SL dBA 46 / 43 48 / 44
Sound Power H dBA 61 63
Drawing No. 3D060038 3D060039
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
5 m
