Specifications SiBE07-724_B
14 Specifications
1.2 Heat Pump
50 Hz, 230 V
Note:
The data are based on the conditions shown in the table below.
The operating sound is based on the rear side suction inlet and the external static pressure 40 Pa.
Operating sound for under side suction inlet : [operating sound for rear side suction inlet] + 5 dB.
However, when installation to which the external static pressure becomes low is carried out, 5 dB or
more may go up.
Models
Indoor Units FDXS25CAVMB FDXS35CAVMB
Outdoor Units
RXS25E2V1B RXS35E2V1B
Cooling Heating Cooling Heating
Capacity Rated (Min. ~ Max.)
kW 2.4 (1.3 ~ 3.0) 3.2 (1.3 ~ 4.5) 3.4 (1.4 ~ 3.8) 4.0 (1.4 ~ 5.0)
Btu/h 8,150 (4,400 ~ 10,200) 10,900 (4,400 ~ 15,350) 11,600 (4,800 ~ 13,000) 13,600 (4,800 ~ 17,100)
kcal/h 2,060 (1,110 ~ 2,580) 2,750 (1,110 ~ 3,870) 2,920 (1,200 ~ 3,260) 3,440 (1,200 ~ 4,300)
Moisture Removal L/h 1.2 — 1.9 —
Running Current (Rated) A 4.0 4.3 5.0 5.5
Power Consumption
Rated (Min. ~ Max.)
W 690 910 1,090 1,180
Power Factor % 75.4 93.1 95.0 93.3
COP (Rated) W/W 3.48 3.52 3.12 3.39
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm VP20 (O.D.
φ
26 / I.D.
φ
20) VP20 (O.D.
φ
26 / I.D.
φ
20)
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Units FDXS25CAVMB FDXS35CAVMB
External Static Pressure Pa 40 40
Airflow Rate
m³/min
(cfm)
H 9.5 (335) 9.5 (335) 10.0 (353) 10.0 (353)
M 8.8 (311) 8.8 (311) 9.3 (328) 9.3 (328)
L 8.0 (282) 8.0 (282) 8.5 (300) 8.5 (300)
SL 6.7 (237) 6.7 (237) 7.0 (247) 7.0 (247)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 62 62
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control – –
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.47 0.47 0.47 0.47
Power Consumption (Rated) W 100 100 100 100
Power Factor % 92.5 92.5 92.5 92.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 200 × 900 × 620 200 × 900 × 620
Packaged Dimensions (H × W × D) mm 266 × 1,106 × 751 266 × 1,106 × 751
Weight kg 25 25
Gross Weight kg 31 31
Operation
Sound
H / M / L / SL dBA 35 / 33 / 31 / 29 35 / 33 / 31 / 29 35 / 33 / 31 / 29 35 / 33 / 31 / 29
Sound Power dBA 53 53 53 53
Outdoor Units RXS25E2V1B RXS35E2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD 1YC23NXD
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 1.00 1.00
Airflow Rate
m³/min
(cfm)
H 33.5 (1,183) 30.2 (1,066) 33.5 (1,183) 30.2 (1,066)
L 23.4 (826) 28.3 (999) 23.4 (826) 28.3 (999)
Fan
Type Propeller Propeller
Motor Output W 23 23
Running Current (Rated) A 3.51 3.78 4.52 5.03
Power Consumption (Rated) W 590 810 990 1,080
Power Factor % 73.1 93.2 95.2 93.4
Starting Current A 4.3 5.5
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 617 × 882 × 363 617 × 882 × 363
Weight kg 32 32
Gross Weight kg 38 38
Operation
Sound
H / L dBA 46 / 43 47 / 44 47 / 44 48 / 45
Sound Power H dBA 61 62 62 63
Drawing No. 3D057653 3D057654
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
7.5 m
