Optional Accessories ED04-702
116 Room Air Conditioners F-Series
14.Optional Accessories
14.1 Option List
Note:
+
1 Wiring adaptor is also required for each indoor unit.
+
2 Time clock and other devices ; obtained locally.
Option Name Kit Name Applicable Model
1 Centralized Control Board-Up to 5 Rooms
+
1 KRC72 Indoor Unit
2
Wiring Adaptor for Time Clock / Remote Control
+
2
(Normal Open Pulse Contact / Normal Open Contact)
KRP413A1S Indoor Unit
3 Central Remote Controller
+
1 DCS302C61 Indoor Unit
4 Unified ON/OFF Controller
+
1 DCS301B61 Indoor Unit
5 Schedule Timer Controller
+
1 DST301B61 Indoor Unit
6 Interface Adaptor for Room Air Conditioner KRP928B2S Indoor Unit
7 Titanium Apatite Photocatalytic Air-Purifying Filter KAF952B42 Indoor Unit
8 The Remote Controller Loss Prevention with the Chain KKF917A4 Indoor Unit
10 Drain Plug KKP937A4 Outdoor Unit
11 Air Direction Adjustment Grille KPW945A4 Outdoor Unit
