ED04-702 Capacity Tables
Room Air Conditioners F-Series 25
8.2 Heat Pump
FTXS50FVMA + RXS50FVMA (50Hz 220-240V / 60Hz 220-230V)
3D055262
Cooling
AFR 14.7
BF 0.18
INDOOR OUTDOOR TEMPERATURE(°CDB)
EWB EDB 20 25 30 32 35 40
°C °C TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20 5.123.741.194.893.621.304.663.511.424.563.461.464.423.391.534.193.281.65
16.0 22 5.353.681.205.123.571.314.893.461.434.793.411.474.653.351.544.423.241.65
18.0 25 5.583.841.205.353.741.325.123.641.435.023.601.484.883.531.554.653.441.66
19.0 27 5.70 4.04 1.21 5.47 3.94 1.32 5.23 3.84 1.44 5.14 3.81 1.48
5.00 3.75 1.55 4.77 3.65 1.66
22.0 30 6.043.901.225.813.811.335.583.721.455.493.691.495.353.631.565.113.551.67
24.0 32 6.273.791.226.043.711.345.813.631.455.723.601.505.583.551.575.343.471.68
Heating
AFR 16.2
INDOOR OUTDOOR TEMPERATURE(°CWB)
EDB –10 –5 0 6 10
°C TC PI TC PI TC PI TC PI TC PI
15.0 3.90 1.35 4.56 1.42 5.21 1.48 6.00 1.56 6.52 1.62
20.0 3.701.394.361.465.011.52
5.80 1.60 6.32 1.65
22.0 3.62 1.40 4.28 1.47 4.93 1.54 5.72 1.61 6.24 1.67
24.0 3.54 1.42 4.20 1.48 4.85 1.55 5.64 1.63 6.16 1.68
25.0 3.50 1.43 4.16 1.49 4.81 1.56 5.60 1.64 6.12 1.69
27.0 3.42 1.44 4.08 1.51 4.73 1.57 5.52 1.65 6.04 1.70
Symbols NOTE:
AFR : Air flow rate (m³/min.) 1. Capacities are based on the following conditions.
(1) Corresponding refrigerant piping length : 7.5m
(2) Level difference : 0m
2. shows nominal (rated) capacities and power input.
BF : Bypass factor
EWB : Entering wet bulb temp. (°C)
EDB : Entering dry bulb temp. (°C)
TC : Total capacity (kW)
SHC : Sensible heat capacity (kW)
PI : Power input (kW)
