ED04-702 Specifications
Room Air Conditioners F-Series 11
4.2 Heat Pump
50Hz 220-230-240V / 60Hz 220-230V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Units FTXS50FVMA FTXS60FVMA
Outdoor Units
RXS50FVMA RXS60FVMA
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 5.0 (1.7~6.0) 5.8 (1.7~7.7) 6.0 (1.7~6.7) 7.0 (1.7~8.0)
Btu/h 17,100 (5,800~20,500) 19,800 (5,800~26,300) 20,500 (5,800~22,900) 23,900 (5,800~27,300)
kcal/h 4,300 (1,460~5,160) 4,990 (1,460~6,620) 5,160 (1,460~5,760) 6,020 (1,460~6,880)
Running Current Rated A 7.2-6.9-6.6/7.2-6.9 7.4-7.1-6.8/7.4-7.1 9.2-8.8-8.4/9.2-8.8 9.4-9.0-8.6/9.4-9.0
Power Consumption
Rated (Min.~Max.)
W 1,550 (440~2,080) 1,600 (400~2,530) 1,980 (440~2,390) 2,040 (400~2,810)
Power Factor % 97.9-97.7-97.9/97.9-97.7 98.3-98.0-98.0/98.3-98.0 97.8-97.8-98.2/97.8-97.8 98.6-98.6-98.8/98.6-98.6
COP
Rated (Min.~Max.)
W/W 3.23 (3.86~2.88) 3.63 (4.25~3.04) 3.03 (3.86~2.80) 3.43 (4.25~2.85)
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30
Max. Interunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FTXS50FVMA FTXS60FVMA
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 14.7 (519) 16.2 (572) 16.2 (572) 17.4 (614)
M 12.6 (445) 13.8 (487) 13.9 (491) 15.3 (540)
L 10.2 (360) 11.5 (406) 11.5 (406) 12.8 (452)
SL 9.2 (325) 10.2 (360) 10.0 (353) 10.5 (371)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.16-0.15-0.15/0.16-0.15 0.17-0.16-0.16/0.17-0.16 0.19-0.18-0.17/0.19-0.18 0.21-0.20-0.19/0.21-0.20
Power Consumption (Rated) W 34 36 40 45
Power Factor % 96.6-98.6-94.4/96.6-98.6 96.3-97.8-93.8/96.3-97.8 95.7-96.6-98.0/95.7-96.6 97.4-97.8-98.7/97.4-97.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 44/40/35/32 42/38/33/30 45/41/36/33 44/40/35/32
Outdoor Unit RXS50FVMA RXS60FVMA
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD
Motor Output W 1,100 1,100
Refrigerant
Oil
Model FVC50K FVC50K
Charge L 0.65 0.65
Refrigerant
Model R-410A R-410A
Charge kg 1.50 1.50
Air Flow Rate m³/min (cfm)
HH 50.9 (1,797) — 54.2 (1,914) —
H 48.9 (1,727) 45.0 (1,589) 50.9 (1,797) 46.3 (1,635)
L 41.7 (1,472) 45.0 (1,589) 45.0 (1,589) 46.3 (1,635)
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 7.04-6.75-6.45/7.04-6.75 7.23-6.94-6.64/7.23-6.94 9.01-8.62-8.23/9.01-8.62 9.19-8.80-8.41/9.19-8.80
Power Consumption (Rated) W 1,516 1,564 1,940 1,995
Power Factor (Rated) % 97.9-97.6-97.9/97.9-97.6 98.3-98.0-98.1/98.3-98.0 97.9-97.9-98.2/97.9-97.9 98.7-98.6-98.8/98.7-98.6
Starting Current A 7.4 9.4
Dimensions (H×W×D) mm 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 792×960×390 792×960×390
Weight kg 48 48
Gross Weight kg 53 53
Operation Sound dBA H:47 SL:44 L:48 SL:45 H:49 SL:46 L:49 SL:46
Drawing No. 3D054879 3D054880
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
