Daikin RKS50FVM [5/125] Intelligent eye
![Daikin RKS50FVM [5/125] Intelligent eye](/views2/1778485/page5/bg5.png)
Features ED04-702
4 Room Air Conditioners F-Series
05RAG06A-7
Intelligent Eye
= Sensing human presence utilizing infrared rays =
05RAG02B- 32
= Just one push of the [SENSOR] button =
Sensor
Intelligent Eye
TIMER
ON
CANCEL
OFF
05RAG06A-9
Cooling
Normal
operation
Energy saving
operation
activated
Power consumption
Saving
20%!
Intelligent Eye
time
Temperature
• 2˚C Shift up
• Minimum frequency
(34Hz)
20min
Absence
Normal
operation
Energy
Saving
operation
Normal
operation
Back to
normal
operation
when
presence
detected
= Automatic shift up when sensing no human, intelligently saving energy =
