Fagor FFJ8845 [15/58] Instruction manual

Instruction manual

Very important: Read this manual carefully before using your refrigerator.

This manual is designed with texts corresponding to drawings.

Installation

Identify the model of your refrigerator (“a”,

“b”, “c”) by comparing the control panel with the

illustrations.

1.1 Unpacking. Remove all protective materials.

1.2 Placement. Place the refrigerator away from

heat sources and protect it from direct sunlight

in order to conserve energy.

Do not install the refrigerator in the open air or

where it is exposed to rain.

Air should be able to circulate behind the

refrigerator. Leave 25 mm between the rear of

the refrigerator and the wall. Do not enclose the

space between the refrigerator and the ﬂ oor or

ceiling with any object.

Level the refrigerator to prevent vibration and

noise. Remember that if the refrigerator is

situated next to a wall or cupboard, it could

make some noise.

In addition, make sure that the trays are

correctly placed and position the containers

with a space between them to prevent

vibration.

1.3 Connecting to power. Let the refrigerator sit

in an upright position for at least 2 hours before

connecting it. Check the information on the

speciﬁ cation plate (220-240V with ground wire)

(1.3.1, 1.3.2).

Do not use adapters or extension leads.

Prevent the cord from coming in contact with

the motor or getting trapped beneath it.

1.4 Changing the side that the door opens from.

Disconnect the refrigerator from the power

outlet and empty the inside of the door.

Remove the upper hinge cover with a ﬂ at blade

screwdriver (1.4.1). Loosen the screws and

remove the hinge mechanism with help of a

screwdriver (1.4.2).

Loosen the connector pressing the tab. (1.4.3).

Remove the refrigerator door (1.4.4). Remove

the controls with a screwdriver, prying it away

using the grooves placed for that purpose

(1.4.5).

Make a notch for the cable on the opposite

Identiﬁ cation

english

side, as marked on the casing (1.4.6). Remount

the control panel passing the cable through the

notch you made (1.4.7)

Remove the screw cover from the central

hinge, loosen the screws and remove the hinge

(1.4.8). In the models with three compartments,

swap the top and bottom hinges. Remove the

freezer door (1.4.9).

Loosen the screws of the lower hinge and remove

it. Change the position of the hinge axis and place

it on the opposite side (1.4.10).

Place the lower freezer handle on the

refrigerator door and the lower refrigerator

handle on the freezer door, rotated 180º.

Place the vertical handles on the opposite side

rotating them 180º (1.4.11). If you have a centre

compartment, place the upper handle below,

and the lower handle above, rotated 180º.

Rotate the self-closures and place the one from

the refrigerator on the freezer and vice versa

(1.4.12).

Position the freezer door (1.4.13) and attach the

central hinge (1.4.14). Position the refrigerator

door (1.4.15).

Place the closure mechanism in the upper

hinge space on the opposite side (1.4.16).

Put the cable through the upper hinge and

rotation mechanism and plug it into the door

connector (1.4.17).

Screw in the upper hinge (1.4.18) and put the

cover in place (1.4.19).

2.1 Switching on the refrigerator. Press

(2.1.1)

(2.1.2) until a temperature appears on the

display.

2.2 Conﬁ guration. Press for 5 seconds and

you will see the different conﬁ guration options

(language, date, time, warnings…) (2.2.1).

Select the option that you would like to

conﬁ gure by pressing

(2.2.2). Change the

option by pressing the

key (2.2.3).

Verify by pressing

(2.2.4). To exit the menu

press

for 5 seconds (2.2.5).

2.3 Selecting the compartment. On combined

refrigerators, the refrigerator, freezer and third

compartment all function separately. Press

to select the compartment until it ﬂ ashes (2.3.1)

and validate by pressing

(2.3.2), or press

the button for the desired compartment:

(2.3.3).

Operation
