SiE18-201 Remote Controller
Operations 155
DISPLAY "▲" (SIGNAL
TRANSMISSION)
DISPLAY " " (SET TEMPERA-
TURE)
DISPLAY " " (PROGRAMMED
TIME)
DISPLAY " " (AIR FLOW FLAP)
DISPLAY " "" " (FAN SPEED)
ON/OFF BUTTON
FAN SPEED CONTROL BUTTON
AIR FLOW DIRECTION ADJUST
BUTTON
OPERATION MODE SELECTOR
BUTTON
FILTER SIGN RESET BUTTON
INSPECTION/TEST OPERATION
BUTTON
EMERGENCY OPERATION SWITCH
RECEIVER
TIMER INDICATOR LAMP (Green)
DEFROST LAMP (Orange)
AIR FILTER CLEANING TIME
INDICATOR LAMP (Red)
OPERATING INDICATOR LAMP (Red)
TEMPERATURE SETTING BUTTON
PROGRAMMING TIME BUTTON
TIMER MODE START/STOP BUTTON
TIMER RESERVE/CANCEL BUTTON
DISPLAY "
TEST
" (INSPECTION/
TEST OPERATION)
This lights up when a signal is being transmitted
Press this button to select OPERATION MODE.
Refer to the section of MAINTENANCE in the
operation manual attached to the indoor unit.
This button is used only by qualified service
persons for maintenance purposes.
This switch is readily used if the remote
controller does not work.
This lamp stays lit while the timer is set.
Lights up when it is time to clean the air filter.
(NOTE)
• For the sake of explanation, all indications are
shown on the display in Figure contrary to
actual running situations.
• If the air filter cleaning time indicator lamp lights
up, clean the air filter as explained in the
operation manual provided with the indoor unit.
After cleaning and reistalling the air filter, press
the filter sign reset button on the remote
controller. The air filter cleaning time indicator
lamp on the receiver will go out.
Lights up when the defrosting operation has
started. (For straight cooling type this lamp
does not turn on.)
This receives the signals from the remote
controller.
This lamp stays lit while the air conditioner
runs. It flashes when the unit is in trouble.
This display shows PROGRAMMED TIME of the
system start or stop.
This display shows the set temperature
This display shows the set fan speed.
Press the button and the system will start.
Press the button again and the system will stop.
Press this button to select the fan speed, HIGH
or LOW, of your choice.
Use this button for programming "START and/or
STOP" time. (Operates with the front cover of
the remote controller opened.)
Use this button for SETTING TEMPERATURE
(Operates with the front cover of the remote
controller closed.)
When the INSPECTION/TEST OPERATION
BUTTON is pressed, the display shows the
system mode is in.
DISPLAY " " " " " " " " " "
(OPERATION MODE)
This display shows the current OPERATION
MODE. For straight cooling type, " " (Auto)
and " " (Heating) are not installed.
C
C
H • M • L
20
21
23
22
NAMES AND FUNCTIONS OF THE
OPERATING SECTION (Fig. 1, 2)
