Daikin RMX140JZVMB [314/344] Caution before operation 303
![Daikin RMX140JZVMB [314/344] Caution before operation 303](/views2/1782301/page314/bg13a.png)
SiE18-201 Wiring
Caution Before Operation 303
RSW1 RSW2 Remarks Unit
41Current BP 1 Room-A gas pipe temperature Temp. offset 40h
42Current BP 1 Room-B gas pipe temperature Temp. offset 40h
43Current BP 1 Room-C gas pipe temperature Temp. offset 40h
44Current BP 2 Room-A gas pipe temperature Temp. offset 40h
45Current BP 2 Room-B gas pipe temperature Temp. offset 40h
46Current BP 2 Room-C gas pipe temperature Temp. offset 40h
47Current BP 3 Room-A gas pipe temperature Temp. offset 40h
48Current BP 3 Room-B gas pipe temperature Temp. offset 40h
49Current BP 3 Room-C gas pipe temperature Temp. offset 40h
50
51Current BP 1 Room-A indoor temperature Temp. offset 40h
52Current BP 1 Room-B indoor temperature Temp. offset 40h
53Current BP 1 Room-C indoor temperature Temp. offset 40h
54Current BP 2 Room-A indoor temperature Temp. offset 40h
55Current BP 2 Room-B indoor temperature Temp. offset 40h
56Current BP 2 Room-C indoor temperature Temp. offset 40h
57Current BP 3 Room-A indoor temperature Temp. offset 40h
58Current BP 3 Room-B indoor temperature Temp. offset 40h
59Current BP 3 Room-C indoor temperature Temp. offset 40h
60
61Current BP 1 Room-A heat exchange temperature Temp. offset 40h
62Current BP 1 Room-B heat exchange temperature Temp. offset 40h
63Current BP 1 Room-C heat exchange temperature Temp. offset 40h
64Current BP 2 Room-A heat exchange temperature Temp. offset 40h
65Current BP 2 Room-B heat exchange temperature Temp. offset 40h
66Current BP 2 Room-C heat exchange temperature Temp. offset 40h
67Current BP 3 Room-A heat exchange temperature Temp. offset 40h
68Current BP 3 Room-B heat exchange temperature Temp. offset 40h
69Current BP 3 Room-C heat exchange temperature Temp. offset 40h
70
71Current BP 1 Room-A ∆D signal ∆D signal
72Current BP 1 Room-B ∆D signal ∆D signal
73Current BP 1 Room-C ∆D signal ∆D signal
74Current BP 2 Room-A ∆D signal ∆D signal
75Current BP 2 Room-B ∆D signal ∆D signal
76Current BP 2 Room-C ∆D signal ∆D signal
77Current BP 3 Room-A ∆D signal ∆D signal
78Current BP 3 Room-B ∆D signal ∆D signal
79Current BP 3 Room-C ∆D signal ∆D signal
80
81Gas short error counter (NGAS) Counter
82Discharge pipe temperature error counter (NOT) Counter
83HPS action counter (NHPS) Counter
84Upper fan lock error counter (NF1LOCK) Counter
85Upper fan OCP error counter (NF1OCP) Counter
86Lower fan lock error counter (NF2LOCK) Counter
87Lower fan OCP error counter (NF2OCP) Counter
88Supply voltage line error counter (NDC) Counter
89Output current line electronic thermal anti-stall counter (NTH) Counter
90Electronic thermal anti-stall counter with position detection waveform (NST) Counter
91Box temperature rise counter (NBOX) Counter
92Radiation fin temperature rise counter (NFIN) Counter
93Compressor lock counter (NCOMP) Counter
94AC current sensor line error counter (NCT) Counter
95Total input over-current error counter (NIINT) Counter
96INV input over-current error counter (NIINV) Counter
97Anti-freeze action counter (NTOU) Counter
98Peak cut action counter (NPC) Counter
99BP indoor anti-freeze error counter (NCOLD HU) Counter
