Method of Field Set SiE18-201

166 Operating Test

2.1.2 Local Setting Mode No.

Example To set the filter sign time to “filter contamination - heavy” for all units in a group:

Set mode No. to “10,” setting switch No. to “0,” and setting position No. to “02.”

Table

Notes: 1. Setting is made in all units in a group. To set for individual indoor units or to check the

setting, use the mode Nos. (with “2” in upper digit) in parentheses ( ).

2. The setting position No. is set to “01” at the factory, except for the following cases in which

“02” is set.

 Setting of air flow direction adjustment range

 Automatic restart after power outage.

 Remote control thermostat

 Filter sign indication (only for ceiling-mounted duct type)

Mode

No.

Note 1

Setting

Switch

No.

Setting Description Setting Position No. *Note 2

01 02 03

10(20) 0 Filter contamination - heavy /

light (Setting of operating hours

for filter sign indication)

(Change setting when

reducing filter sign indication

time to half due to quick soiling

of filter)

Ultra-Long-

Life Type

Light Approx.

10,000

hours

Heavy Approx.

5,000

hours

—

Long-Life

Type

Approx.

2,500

hours

Approx.

1,250

hours

Standard

Type

Approx.

200

hours

Approx.

100

hours

1 Long-life filter type (Setting of filter sign

indication time)

(Change setting when Ultra-long-life filter is

installed)

Long-Life Filter Ultra-Long-Life

Filter (1)

Setting Description

Ultra-Long-Life

Filter (2)

3 Estimation of filter operating hour

(Change setting when filter sign indication is

not used)

ON OFF —

11(21) 0 No. of Sky Air indoor units connected for

simultaneous ON-OFF multi system

(Change setting when simultaneous

operation multi system is used) *Note 3

Pair Twin Triple

1 Simultaneous operation multi-unit individual

setting

Unified Individual —

2 Indoor unit fan OFF when cooling/heating is

OFF

— Fan OFF —

12(22) 3 Change to set fan speed when heater

thermostat is OFF *Note 5

Fan Speed LL Set Fan Speed —

5 Automatic restart after power outage reset

*Note 6

OFF ON —

13(23) 0 High

Ceiling

Ceiling-mounted built-in multi-flow

cassette type, Ceiling suspended

cassette type

NHS

Ceiling-suspended type, wall-

mounted type

2.7 m or Lower 2.7~3.5 m —

Fan speed increase (wall-mounted type) Standard Slight Increase Normal Increase

1 Air flow direction selection (Change setting

when blocking kit is installed) *Note 4

FTW

3 Air flow direction adjustment (Change setting

when decorative air outlet panel is installed)

Installed Not Installed —

4 Setting of air flow direction adjustment range Upward Standard Downward

5 On-site fan speed change by air outlet

(When using phase control)

Standard Option 1 Option 2

6 External static pressure setting (To be set

according to connected duct resistance)

(High ceiling setting in the case of FHYK)

Standard

(Standard)

High Static

Pressure (High

Ceiling Setting)

Low Static Pressure
