Troubleshooting - Outdoor Unit Related SiE18-201
224 Service Diagnosis
3.3.13 Faulty Discharge Thermistor
Outdoor Unit
Indication
J3
Method of
Malfunction
Detection
Malfunction
Decision
Conditions
When the discharge temperature sensor became short-circuited or open.
Supposed
Causes
Faulty discharge temperature sensor
Faulty connectors connection of discharge temperature sensor
Troubleshooting
AB
1 -10˚C 117kΩ
2 0˚C 67kΩ
3 10˚C 40kΩ
4 20˚C 25kΩ
5 30˚C 16kΩ
6 40˚C 10kΩ
7 50˚C 7kΩ
8 60˚C 5kΩ
9 70˚C 3kΩ
Disconnect the thermistor
connectors from outdoor unit
PC board and measure the
resistance of discharge
temperature sensor.
Replace thermistor or
thermistor assembly.
If insufficient contact is not
detected, replace outdoor
unit PC board.
YES
Is the resistance
normal referring to the table
below?
NO
(MF032)
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
