Si04-115 For FTK25J, FTK35J, FTX25J, FTX35J
Removal Procedure 115
6
Disengage a hook from
the backward.
7
Since the fan bearing is
made of rubber, push it
strongly off from the
inside. The bearing can
be removed just as the
left-side plate is
attached with.
