For RK25J, RK35J, RX25J, RX35J Si04-115
118 Removal Procedure
5
The front plate and the
left side plate can be
removed when the one
fixed screw is removed.
"
Sectional view at the front.
Step Procedure Points
Top plate
Left side
plate
The edge of the top plate
gets into this groove.
(R1737)
