Daikin FTX35JV1NB9 [140/162] To remove the reactor
![Daikin RK25JV1NB9 [140/162] To remove the reactor](/views2/1782498/page140/bg8c.png)
Si04-115 For RK25J, RK35J, RX25J, RX35J
Removal Procedure 131
4
When restoring the
partition plate, put the
hook into the bottom
frame.
2. To remove the reactor
1
The reactor can be
removed by removing
the fixed screw.
Step Procedure Points
