CAPACITIES - LUBRICANTS
MT-15
[JH3]
D
E
F
G
H
I
J
K
L
M
A
B
MT
CAPACITIES - LUBRICANTS PFP:32010
Description
BCS000LE
Fill to the level of the oil filler cap hole.
Capacity Grade
2.6 (4-5/8 Imp pt)
Nissan Genuine gear oil Passenger Car or
API GL-4 Viscosity 75W-80
MCIB0015E
