Sony VPCB11X9E/B [105/206] Using the multiple monitors function

Sony VPCB11A7E [105/206] Using the multiple monitors function

105

Using Peripheral Devices >

Using the Multiple Monitors Function

The Multiple Monitors function allows you to distribute portions of your desktop across separate displays. For example, if you

have an external display connected to the monitor port, your computer screen and the external display can function as a

single desktop.

You can move the cursor from one display to the other. This allows you to drag objects, such as an open application window

or a toolbar, from one display to the other.
