Sony VPCB11X9E/B [98/206] Connecting an external display

Using Peripheral Devices >

Connecting an External Display

You can connect an external display (not supplied) to your computer. For example, you can use the computer with a computer

display or a projector.

Some features and options in this section may not be available on your computer.

✍

Connect the power cord of your external display after connecting all other cables.
