Sony VPCB11X9E/B [146/206] Handling the built in camera

146

Precautions >

Handling the Built-in Camera

Some features and options in this section may not be available on your computer.

See the specifications to find out about the configuration of your computer.

❑ Do not touch the lens protection cover of the built-in camera, as it may cause scratches on the cover and such scratches

will appear on the captured images.

❑ Do not let the direct sunlight get into the lens of the built-in camera regardless of your computer's power state, as it may

cause the camera to malfunction.
