Sony VPCB11X9E/B [133/206] Removing and installing a memory module

133

Upgrading Your VAIO Computer >

Adding and Removing Memory

Removing and Installing a Memory Module

To change or add a memory module

1 Shut down the computer and disconnect all peripheral devices.

2 Unplug the computer and remove the battery pack.

3 Wait about an hour until the computer cools down.

4 Unscrew the screw (indicated by the arrow below) on the bottom of the computer and remove the memory module

compartment cover.

5 Touch a metal object to discharge static electricity.
