3. Scope of use
The compressor is designed for generating
compressed air for tools operated by compressed
air.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
4. Technical data
Power supply: 230 ~ 50 Hz
Motor rating in kW: 1.5
Operating mode S3 25%
Idle speed n
0
: 4000
Operating pressure in bar: 10
Pressure vessel volume in litre: 50
Theoretical intake rate in l/min.: 240
Sound power level L
WA
in dB: 97
Protection type: IP20
Machine weight in kg: 22.2
S3 25%: Intermittent mode, no start-up, no braking
(cycle duration 10 minutes) In intermittent mode, the
percentage load factor (25%) is always quoted so
that the heat generated during this period can be
dissipated during breaks in operation by convective
cooling. Intermittent mode consists of the on time and
the cooling breaks, known as the duty cycle.
The period of consideration is 10 minutes. 25 % load
factor means that the electric tool can be operated for
2.5 minutes at the rated performance, followed by a
cooling phase of 7.5 minutes.
The noise emission values were measured in
accordance with EN ISO 3744.
5. Points to note when setting up the
compressor
Examine the machine for signs of transit
damage. Report any damage immediately to the
company which delivered the compressor.
The compressor should be set up near the
working consumer.
Avoid long air lines and long supply lines
(extensions).
Make sure the intake air is dry and dust-free.
Do not set up the compressor in damp or wet
rooms.
The compressor may only be used in suitable
rooms (with good ventilation and an ambient
temperature from +5°C to +40°C). There must be
no dust, acids, vapors, explosive gases or
inflammable gases in the room.
The compressor is designed to be used in dry
rooms. It is prohibited to use the compressor in
areas where work is conducted with sprayed
water.
The oil level in the compressor pump has to be
checked before putting the equipment into
operation.
6. Assembly and starting
Important!
You must fully assemble the appliance before
using it for the first time.
6.1. Fitting the supporting foot (4)
Fit the supplied rubber stopper as shown in Fig. 4.
6.2. Fitting the wheels (3)
Fit the supplied wheels as shown in Figure 5 and
Figure 6.
GB
14
