138
Applications
1. Standard Hybrid operation
1.1. Standard Hybrid operation with a tank
With this application, the system works in a perfect
balance between the gas boiler and the heat pump
to provide space heating and domestic hot water.
Here, the boiler is able to heat directly the water
without a tank.
In this application, a domestic
hot water tank can be added
if the system needs to provide
high quantity of domestic hot
water produced either by the
heat pump or by the boiler.
2.. Add-on operation
Daikin Altherma H Hybrid
outdoor unit can be combined
with an existing boiler. In such
application, the system works
in bivalent operation, meaning
that this is strictly the heat pump
or the boiler that is providing
the required heat while in the
standard applications, both can
work at the same time.
Motorised
3-way valve
Watertank
EJHA-AV
EHYKOMB-A
User interface
EHYKOMB-A
Outdoor Indoor
EJHA-AV
Outdoor Indoor
User interface
Outdoor
EJHA-AV
Indoor
User interface
Third-party Gas boiler
Non-return valves
(eld supply)
Pump
