Solar panel - pressurised system
Article Type Order No.
Controller
Temperature-dierence regulator for the solar panel with pressure
system. Regulator with graphic display for representation of
hydraulic schematics and yield balances, for example. Including
return ow and storage tank temperature sensor and housing for
wall mounting.
EKSDSR1A EKSDSR1A
Pressure station
Consists of: Pipe connection ø 22 mm including pipe compression
ttings and support sleeves (5x), ow measurement unit with 2 x
KFE cock, integrated air separator, ball-cocks with integrated back-
ow prevention, Grundfos Solar 25-65 pump, safety group with
pressure gauge, including insulation and installation accessories.
EKSRDS2A EKSRDS2A
Fill and drain connection
For RPS3 and tanks from 2013 onwards, for easy lling and
emptying through the ll and drain valve.
KFE BA 16 52 15
Solar panel pressurised
solar line DN 16
15 m thermally-insulated stainless steel corrugated pipe line for
solar panel pressurised systems with inserted sensor line nominal
size DN 16. For systems of up to 3 solar panels and a line length of
up to 25 m. Without connection ttings.
CON 15P16 16 20 73
Solar panel pressurised
solar connection kit DN 16
All necessary ttings for connecting the pressurised solar line DN
16. Required together with CON 15P16.
CON CP16 16 20 75
Solar panel pressurised
solar connection kit DN 16
Fittings for connecting two pressurised solar lines DN 16. CON XP16 16 20 71
Solar panel pressurised
solar line DN 20
15 m thermally-insulated stainless steel corrugated pipe line for solar
panel pressurised systems with inserted sensor line nominal size DN
20. For systems up to 5 solar panels and a line length of up to 25 m.
Without connection ttings.
CON 15P20 16 20 74
Pressurised solar
connection kit DN 20
All necessary ttings for connecting the pressurised solar line DN 20.
Always required together with CON 15P20.
CON CP20 16 20 76
Solar panel pressurised
solar connection kit DN 20
Fittings for connecting the pressurised solar line DN 20. CON P20 16 20 72
Installation material solar
panel pressurised system
Connection ttings for pressurised systems and solar panel
installation material, consisting of installation material for solar
panel and connection pipe, 2 m UV-proof thermal insulation for
the outer area, connection ttings and panel temperature sensor.
The roof penetration must be provided to the customer.
RCP EKSRCP
Solar panel row
connection for the solar
panel with
pressure system
Connection kit for connecting two rows of solar panels in parallel.
Consisting of solar panel installation material, equipotential
bonding terminals, end caps, connection elbows and 1 m
thermally-insulated piping.
CONLCP 16 20 45
