Your comfortable climate,
day after day
Desired temperature at any time of year
Our heating systems make for a comfortable home.
Heatgenerators such as an air-water heat pump use regenerative
environmental energy as a heat source and so reduce energy
consumption and keep costs to aminimum. But what about
air conditioning of therooms in summer? Very few residential
buildings have air conditioning for a pleasant and comfortable
temperature even on hot summer days and nights. That's changing
now. With a heating system that not only provides comfortable
warmth in winter, but also gentle cooling in summer throughout
the entire building. And all this with very economical operation
and no additional purchase costs.
Regenerative heating in winter,
gentle cooling in summer
The Daikin heat pump really comes into its own when combined
with a Daikin underfloor heating system. Forcooling, the heat
pump process is simply reversed, i.e. heat is extracted from the
building and released into the environment. The room is cooled
mainly by the underfloor heating system. The large surface makes
for a very pleasant and draught-free room climate. Invisible and
noiseless, even in cooling mode.
Clever combination:
Underfloor heating and convector fan
A convector fan is used in rooms without underfloor heating to
handle the dual functions of heating and cooling. It is the ideal
complement to the Daikin heat pump if not all rooms have
underfloor heating. Its very quiet operation means it can even
beused in bedrooms. The integrated electronic room temperature
control unit ensures an optimal climate in every room.
Maximum comfort and maximum savings –
all-inclusive
With the existing or optionally available cooling function of
theDaikin air-water heat pump, you can enjoy both heating and
cooling in rooms with underfloor heating without any further
outlay or investment. The operating costs for this additional
comfort are alsolow.
Daikin Altherma ST solar thermal sytem:
Minimizesenergy costs
The integration of a solar system, which additionally contributes
heating in winter from free solar energy, offers maximum living
comfort with minimal energy costs.
System temperatures 35 °C - 45 °C System temperatures 55 °C - 70 °C Option
Areas of application: Monopex Monopex cut Monopex
Industrial
System 70 System 70
Industrial
Heat pump
convector
New building ( )*
Modernisation with additional height
Modernisation without additional height
Underfloor heating combined with radiator
Heating and cooling
(in combination with heat pump)
Wall heating
Large areas
Heat generators
Boilers
Heat pump (low-temperature heating)
* If system temperature of the heat generator requires 55 °C - 70 °C in the flow line
Daikin Altherma UFH
Underoor heating
