Protect system plate
The Protect system plate
consists of a nub plate with an
additional surface protection
layer made of deep-drawn
polystyrene to protect the
heating pipe during installation.
Systems: Monopex, System 70
Tacker system
The Daikin tacker panel for
underfloor heating pipes is
available as a folding panel
and roller track with laminated,
high-strength film, and is ideal
for laying heating pipes over
large surfaces (e.g. commercial
buildings).
Systems: Monopex
Room controller
The room thermostat
ensures convenient and
individual control of the room
temperature and impresses with
its flat design and construction.
Versions:
Wireless version
› Wireless without battery
Wired version
› LED display:
Heating/cooling (red/blue)
› Read all status messages
RMX heating circuit manifold
Heating circuit manifold made
of heat-stabilised, glass fiber
reinforced polyamide. For all
Daikin underfloor heating and
radiator connection systems.
Basic module with integrated
power pack and clock module
› Basic module with integrated
power pack to supply
thecontrol unit (wireless and
wired) plus optional clock
module
› Optimal interface to Daikin
heat generators
Monopex
The underfloor heating for low
system temperatures. Ideal in
combination with heat pumps.
› Monopex 14 for floor
structures with system or
tacker panel, wall heating
and
the Daikin milling system
› Monopex 16 (for France) for
floor installation with system or
tacker panels
› Monopex 17 for floor
installation
with system or
tacker panels
› Monopex 20 for commercial
and industrial surfaces
System 70
Underfloor heating for direct
combination with radiators
or other heating surfaces.
Differentpipe dimensions for
different applications.
› DUO 17 for floor mounting
with system panels
› DUO 25 for commercial and
industrial areas
Daikin Altherma HPC heat
pump convector
› Slim design
› Heating and cooling
› Integrated electronic room
temperature controller
withtimer
› Very quiet and compact
›
Also suitable for bedrooms
› Ideal in buildings with
underfloor heating and
radiators
RMV heating circuit
distributor
Heating circuit manifold in
stainless steel. For all Daikin
underfloor heating and
radiator connection systems.
Clip rail for wall heating
Clip rail combined with
Monopex 14 for wall heating.
Systems: Monopex 14
Clock module to supplement
basic module:
›
2 reduction times for
heatingcircuits
› Pump stopping time
› Removable from the basic
module for easy operation
Heat pump convectors
