Hitachi M12V2 [9/54] English

English

PRIOR TO OPERATION

1. Power source

Ensure that the power source to be utilized conforms

to the power requirements specified on the product

nameplate.

2. Power switch

Ensure that the power switch is in the OFF position.

If the plug is connected to a receptacle while the

power switch is in the ON position, the power tool

will start operating immediately, which could cause

a serious accident.

3. Extension cord

When the work area is removed from the power

source, use an extension cord of sufficient thickness

and rated capacity. The extension cord should be

kept as short as practicable.

INSTALLING AND REMOVING BITS

WARNING

Be sure to switch power OFF and disconnect the

plug from the receptacle to avoid serious trouble.

1. Installing bits

(1) Clean and insert shank of bit into the collet chuck

until shank bottoms, then back it out approximately

2 mm.

(2) With the bit inserted and pressing the lock pin

holding the armature shaft, use the 23 mm wrench

to firmly tighten the collet chunk in a clockwise

direction (viewed from under the router). (Fig. 1)

CAUTION

䡬 Ensure that the collet chuck is firmly tightened after

inserting a bit. Failure to do so will result in damage

to the collet chuck.

䡬 Ensure that the lock pin is not inserted into the

armature shaft after tightening the collet chuck.

Failure to do so will result in damage to the collet

chuck, lock pin and armature shaft.

(3) When using the 8 mm diameter shank bit, replace

the equipped collet chuck with the one for 8mm

diameter shank bit which is provided as the standard

accessory.

2. Removing Bits

When removing the bits, do so by following the

steps for installing bits in reverse order.

CAUTION

Ensure that the lock pin is not inserted into the

armature shaft after tightening the collet chuck.

Failure to do so will result in damage to the collet

chuck, lock pin and armature shaft.

HOW TO USE THE ROUTER

1. Adjusting depth of cut (Fig. 2)

(1) Place the tool on a flat wood surface.

(2) Turn the quick adjustment lever in a

counterclockwise direction until the quick adjustment

lever stops. (Fig. 3)

(3) Turn the stopper block so that section to which the

cutting depth setting screw on a stopper block is

not attached comes to the bottom of the stopper

pole. Loosen pole lock knob allowing the stopper

pole to contact with stopper block.

(4) Loosen the lock lever and press the tool body until

the bit just touches the flat surface. Tighten the lock

lever at this point. (Fig. 4)

(5) Tighten pole lock knob. Align the depth indicator

with the “0” graduation of scale.

(6) Loosen pole lock knob, and raise until indicator

aligns with the graduation representing the desired

cutting depth. Tighten pole lock knob.

(7) Loosen the lock lever and press the tool body down

until the stopper block to obtain the desired cutting

depth.

Your router allows you to finely adjust depth of cut.

(1) Attach knob to fine adjustment knob.

(2) Turn the quick adjustment lever in a clockwise

direction until the quick adjustment lever stops with

the stopper screw. (Fig. 5)

If the quick adjustment lever does not stop with the

stopper screw, the bolt screw is not properly fitted.

If this occurs, slightly loosen the lock lever and

press down on the unit (router) hard from the top

and turn the quick adjustment lever again after

properly fitting the bolt screw.

(3) The depth of cut can be adjusted when the lock

lever is loosened, by turning the fine adjustment

knob. Turning the fine adjustment knob

counterclockwise results in shallower cut, whereas

turning it clockwise results in a deeper cut.

CAUTION

Ensure that the lock lever is tightened after finely

adjusting depth of cut. Failure to do so will result

in damage to the quick adjustment lever.

2. Stopper block (Fig. 6)

The 2 cut-depth setting screws attached to the

stopper block can be adjusted to simultaneously set

3 different cutting depth. Use a wrench to tighten

the nuts so that the cut-depth setting screws do not

come loose at this time.

3. Guiding the router

WARNING

Be sure to switch power OFF and disconnect the

plug from the receptacle to avoid serious trouble.

(1) Template guide adapter

1 Loosen the 2 template guide adapter screws, so that

the template guide adapter can be moved. (Fig. 8)

2 Insert the centering gauge through the hole in the

template guide adapter and into the collet chuck.

(Fig. 9)

3 Tighten the collet chuck by hand.

4 Tighten the template guide adapter screws, and pull

out the centering gauge.

(2) Template guide

Use the template guide when employing a template

for producing a large quantity of identically shaped

products. (Fig. 10)

As shown in Fig. 11, to install insert template guide

in center hole in template guide adapter with 2

accessory screws.

A template is a profiling mold made of plywood

or thin lumber. When making a template, pay

particular attention to the matters described below

and illustrated in Fig. 12.

When using the router along the interior plane of

the template, the dimensions of the finished product

will be less than the dimensions of the template

by an amount equal to dimension “A”, the difference

Hitachi M12V2 [9/54] English
