Haier HWE06XCN [13/25] Final installation

renoitidnoC riA citsemoD

Installation and Accessory Parts

Final installation

1. Uncoil the included foam seal.(See Fig.12)

2. Insert the foam seal behind the top of the lower window sash and against the glass of the upper window.

3. Place the window lock bracket as shown in the diagram using a screwdriver. Use a 1/8" drill bit to drill a starter

hole through the hole in the window lock bracket and into the upper window. (See Fig.13)

4. Attach the window lock bracket to the upper window with one (1) 1" wood screw to secure the unit in place.

Plug unit into a grounded 3 prong outlet.

6. Press RESET on the power supply cord. A green light will come on. See “Electrical Requirements" for full detail.

Fig. 12

Fig. 13
