![Haier HWE06XCN [4/25] Specification](/views2/1820191/page4/bg4.png)
2.Specification
Item Unit ESA406M
Cooling capacity BTU/h 6000
Heating capacity BTU/h /
Power supply 1PH/115V/60HZ
Power input W 560
Running current A 5.5
Cooling
EER BTU/(h·W) 10.7
Power input W /
Running current A /
Heating
COP BTU/(h·W) /
Indoor side dB(A) 54
Sound Level
Outdoor side dB(A) 58
Height inches 12 7/16
Width inches 18 1/2
Net dimensions
Depth inches 41
Height inches 51
Width inches 20 1/4
Packaging
dimensions
Depth inches 17 3/4
Net kg
kg
Weight
Gross
Type Rotary
Model / YZG-A053Y2D2T1
Compressor
Running cap. For comp. µF 40
Hi-Pressure Psig 500
Pressure
Low-Pressure Psig 240
Model
R22 or
R410A
R410A
Refrigerant
Charge OZ 14.1
Indoor unit / centrifugal
Type
Outdoor unit / axial
Fan
Fan Speed Indoor unit r/min
Air volume CFM 160
Moisture removal Pints/hr
2.4
20.4
22.7
1460/1350/1250
Specification
Domestic Air Conditioner
2
