![Haier HWE06XCN [23/25] R e n oitid n o c ri a cits e m o d 21](/img/pdf.png)
Haier HWE06XCN [23/25] R e n oitid n o c ri a cits e m o d 21
![Haier HWE06XCN [23/25] R e n oitid n o c ri a cits e m o d 21](/views2/1820191/page23/bg17.png)
Circuit Diagram
renoitidnoC riA citsemoD
21
1
2
3
4
56
7
8
9
10
LED1
ZDD-0362G-R21
LED2
P4
SS8550
P2
SS8550
P3
SS8550
P5
SS8550
+5V
+5V
+5V
+5V
+5V
R29
R27
R28 R30
1
2
3
REV1
HS0038B
R24
R44
R43
R42
R41
R40
R39
R38
R37
R11
R21
R12R31
R151
R150
R18 R19 R62 R56 R60
R61 R1
R153
R152
LED13
R45
+5V
PG2
1
PG1
2
VCC
3
C
4
PPG21/P67
5
PPG20/P66
6
PPG11/P65
7
PPG10/P64
8
PPG01/P63
9
PPG00/P62
10
INT09/P61
11
INT08/P60
12
P00/INT00/AN00
13
P01/INT01/AN01
14
P02/INT02/AN02
15
P03/INT03/AN03/SOT
16
P04/INT04/AN04/SIN
17
P05/INT05/AN05
18
P06/INT06/AN06
19
P07/INT07/AN07
20
P10/PPG10
21
P11/PPG11
22
P12/DBG
23
P13/PPG00
24
P14/PPG01
25
P15/PPG20
26
P16/PPG21
27
P17
28
PF2/RST
29
X0/PF0
30
X1/PF1
31
VSS
32
IC1
MB95F334K-LQFP32
R65
R66
+5V
R155
R154
+5V
R157
R156
+5V
R7
+5V
R81
R159
R158
+5V
N1
SS8050
R82
+5V
+5V
D10
RLS4148
R46
D11
RLS4148
D12
RLS4148
D13
RLS4148
D14
RLS4148
D15
RLS4148
D16
RLS4148
R47
+5V
MODESPEED
TIMER
NWODPUPOWER
FILTER RESET
+5V
R70 R71 R72
C1
0.1uF
E1
100uF-16V
E3
100uF-16V
C2
0.1uF
C14
0.1uF
1
2
3
4
5
6
7
8
9
10
CON1
C4
0.1uF
C3
0.1uF
C11
0.001uF
E2
4.7uF-50V
SW1 SW5 SW3 SW7 SW2 SW6 SW4
LED3 LED4
LED5
LED7
LED6
LED8 LED9LED10 LED11 LED12
R48
LED14
C9
0.1uF
