Haier HWE06XCN [14/25] Side curtains 2 side curtain frames 2 remote control
![Haier HWE06XCN [14/25] Side curtains 2 side curtain frames 2 remote control](/views2/1820191/page14/bge.png)
Installation and Accessory Parts
Domestic Air Conditioner
12
Parts
Tools
Check that all parts for your specific air conditioner are included in parts package.
■
Phillips head screwdriver
■ Scissors
■ Level
■ Tape measure
■
Pencil
■
Drill and 1/8” bit
ON/OFF
MODE
SPEED
TIMER
TEMP/TIME
TEMP/TIME
Top channel Foam seal Side bracket(2)
Window lock bracket 3/8" self tapping
screws(3)
1" wood screws(9)
Side curtains(2) Side curtain frames(2) Remote control
