Description part and function
6
Parts and Functions
The air flow direction can be adjusted
with the vertical and horizontal louvers
INLET GRILLE
MOLD PROOF
AIR FILTER
LOUVER
VERTICAL LOUVER
AIR PURIFYING FILTER
POWER PLUG
REMOTE SIGNAL
RECEIVER
HORIZONTAL LOUVER
Beeping sound assures successful
signal transmission between
wireless remote controller and the
indoor unit.
For models:
AS122ALAHA
(HSU-12HH03(B))
Indoor Unit
The air flow direction can be adjusted
with the vertical and horizontal louvers
INLET GRILL
MOLD PROOF
AIR FILTER
LOUVER
VERTICAL LOUVER
AIR PURIFYING FILTER
POWER PLUG
REMOTE SIGNAL
RECEIVER
HORIZONTAL LOUVER
Beeping sound assures successful
signal transmission between
wireless remote controller and the
indoor unit.
For models:
AS122AMAIA
(HSU-12HO03(B))
The air flow direction can be adjusted
with the vertical and horizontal louvers
INLET GRILL
MOLD PROOF
AIR FILTER
LOUVER
VERTICAL LOUVER
AIR PURIFYING FILTER
POWER PLUG
REMOTE SIGNAL
RECEIVER
HORIZONTAL LOUVER
Beeping sound assures successful
signal transmission between
wireless remote controller and the
indoor unit.
For models:
AS122AMAHA
(HSU-12HF03(B))
