Haier HSU-12HF03(B) [30/63] Operation
![Haier HSU-12HF03(B) [30/63] Operation](/views2/1823893/page30/bg1e.png)
Power mode operation includes super mode operation and soft mode
operation.
Power Mode Operation
Operation
The indication appears on the remote controller
at one press and it goes out at the second press, then
the operation will return to the regular operation.
Press Power Mode Switch twice.
OFF
The indication appears on the remote controller
and the operation in Super Mode starts.
During the Super Mode operarion, the air flow speed
is indicated as "AUTO" on the controller.
Press Power Mode Switch once.
ON
NOTE
This mode is good to have yourself blown
directly to feel cooler or warmer.
Unevenness of room air temperature may occur due to the intensive operation in a
short time.
Super Mode Operation
LOCK
RESET CODE
MODE
SWING
POWER/SOF
T
TIMER
A
FAN
TEMP
ON
OFF
