Haier HSU-12HF03(B) [31/63] Operation
![Haier HSU-12HF03(B) [31/63] Operation](/views2/1823893/page31/bg1f.png)
Power mode operation includes super mode operation and soft mode
operation.
Power Mode Operation
Operation
The indication goes out at one press, then the
operation will return to the regular operation.
Press Power Mode Switch twice.
OFF
The indication appears on the remote controller
and the operation in Soft Mode starts.
During the Soft Mode operarion, the air flow speed is
indicated as "AUTO" on the controller.
Press Power Mode Switch once.
ON
Soft mode opertion may not be powerful enough to keep the room temperature at the
designated for a long time.
NOTE
Soft mode operation, operating more
quietly by controlling the air flow of indoor
unit, it is useful when noises should be
smaller, such as, for reading and sleeping.
Soft Mode Operation
LOCK
RESET CODE
MODE
SWING
POWER/SOF
T
TIMER
A
FAN
TEMP
ON
OFF
