Haier HSU-12HF03(B) [32/63] Operation
![Haier HSU-12HF03(B) [32/63] Operation](/views2/1823893/page32/bg20.png)
Timer Function Usage
With this function, the system stops
operating after the designated period.
Operation
Press either or time setting switch to adjust the operating
period.
The timer then immediately start its function.
Changing the Designated
Period
Just press the timer mode switch several times until
TIMER mode disappears.
Timer Cancellation
4
Press the ON/OFF switch
Make sure that the operating conditions are those
desired.
Set the timer mode to "OFF"
by pressing the timer mode
switch.
Make sure that the timer mode indicator of the indoor
unit lights up.
Set the operation period by
pressing the time setting
switches.
The operation period can be set from 1 hour to 12
hours by an hour.
1
2
3
Timer OFF Function
OFF
LOCK
RESET CODE
MODE
SWING
POWER/SOF
T
TIMER
A
FAN
TEMP
ON
OFF
H
1
2
3
4
