Panasonic CU-HE12NKE [90/110] Disassembly and assembly instructions

WARNING

16. Disassembly and Assembly Instructions

High Voltage is generated in the electrical parts area by the capacitor. Ensure that the capacitor has discharged sufficiently before proceeding with

repair work. Failure to heed this caution may result in electric shocks.

16.1 Indoor Unit

16.1.1 Indoor Electronic Controllers, Cross Flow Fan and Indoor Fan Motor Removal

Procedures

16.1.1.1 To remove front grille

Figure 1

16.1.1.2 To remove electronic controller

Figure 2
