ENGLISH
The appliance must be installed by a qualified person in compliance with the instructions provided.
WARNING: Failure to install the screw or fixing device in accordance with these instructions may result
in electrical azard.
Only for hoods with electronic control:
The 4th speed (intensive) is automatically lowered to 3rd speed after 5 minutes of operation to optimise energy
consumption.
- If the hood is left on (lights and/or motor), after 10 hours in the absence of commands from the user, it will automatically
switch to OFF condition with all services switched off. In hoods with voltage 120V/60Hz this function is not active.
- In the event of interruption of power during the hood, if you restore the hood in the OFF state, then the engine must
be reactivate manually.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
Wear gloves when carrying out installation and maintenance operations.
DESCRIPTION
The unit can be found in filtering hoods, exhaust hoods or in hoods with an outside motor. In the Filtering hoods
(Fig. 1) the air and steam taken up by the unit are purified with charcoal filters and returned to the environment
through the aeration grids on the side of the flue. WARNING: When using filtering hoods, both charcoal filters
and an air deflector (A) must be used. Located in the lower part of the flue, this deflector recycles the air
to the environment. The charcoal filters are not supplied. In the Exhaust hoods (Fig .2) an exhaust duct conveys
the steam and cooking odors directly outside through the wall/ceiling. Therefore they do not require charcoal
filters. In the hoods with an outside motor (Fig. 3), a vacuum suction unit must be connected; this exhaust
will operate separately, conveying the exhaust air through the unit. Only use vacuum units suggested in the
original catalogue.
INSTALLATION
To facilitate installation, before starting remove the grease filters: press inward on the clamp at the handle and
pull the filter downward (Fig.4).
Wall fitting (Fig.5): Draw a line on the wall in vertical line with your hob. Mark the first 2 holes to be drilled
in the wall, respecting the distances indicated in Fig. 5. Drill the 2 holes and fit the screws (A) and screw anchors
provided. As already specified on the “Warning” sheet, bear in mind that the distance between the lower edge
of the hood and the hob must be min. 650 mm. Hang the hood (Fig. 6). Adjust the horizontal position moving
the hood to the right or left so that it is aligned with the wall units. When adjustment has been completed, without
removing the hood, mark the other 2 holes to be drilled (B) in the wall. Remove the hood and drill the holes
marked (8 mm diameter). Then use the 2 screw anchors and the 2 screws provided for final fixing (4.8x38mm).
To avoid damage make exclusive use of the holes already prepared on the hood.
Securing the telescopic flue: Basic installation requirements: – Set the electrical power supply within the space
covered by the decorative flue. – If your unit is installed in an Exhaust hood or in a hood with outside motor,
prepare the air exhaust hole.
Place bracket (W) 50 mm from the ceiling and position this on the vertical of your hood, with the aid of the
notches on the centre of the bracket (Fig.7); using a pen, mark the 2 holes on the wall and then make the holes
and fit the screw anchors provided and proceed to secure the bracket using the 2 screws (provided).
Exhaust hoods and hoods with outside motors: connect the disposal duct to the air evacuation pipe of the hood;
use a flexible pipe and lock it to the air evacuation pipe of the hood with a metal hose clamp (pipe and clamp
are not provided).
Only for models with outside motor (Fig. 8): plug the hood into the outside control unit using the special terminal block:
remove wire clamp A and lid B from the wiring junction box. Secure the wire connecting the control unit to terminal C.
Then replace wire clamp A and lid B on the wiring junction box.
Make all power connections to the hood by means of the power cable. Take 2 assembled flues and place these
on the upper surface of the hood. Raise the upper flue as far as the ceiling and secure it to the bracket using
the 2 screws (Fig.9).
Filtering hood: make all power connections to the hood using the power cable. Fasten the air baffle to the lower
flue as shown in Figure 10, using the 2 screws. Take 2 assembled flues and place these on the upper surface
of the hood. Raise the upper flue as far as the ceiling and secure it to the bracket using the 2 screws (Fig.9).
Also remember that charcoal filters must be used in the case of the filtering version; check to see whether such
filters are already fitted; if necessary, proceed to fit as follows, depending on the model type purchased:
- if the hood features round charcoal filters (Fig. 11), fit the charcoal filter by turning clockwise.
- if the hood features a panel type charcoal filter (Fig. 12), remove the two metal filter retainers (M) and position
the charcoal filter inside the grease filter; fit the two filter retainers back on again to secure the charcoal filter.
