OPERATION
Depending on the model, the unit is equipped with the following controls:
Controls shown in Fig. 13:
Button A: light switch. Button B: first speed motor ON/OFF switch.
Button C: second speed switch. Button D: third speed switch.
Controls shown in Fig. 14:
Button A: Light switch; position 0: light off; position 1: light on. Button B: Motor
switch; position 0: motor off; position 1-2-3: motor on at speed I, II and III.
Controls shown in Fig. 15:
Key A = Light ON/OFF switch.
Key B = Motor ON/OFF switch - Speed I
Key C = Motor ON/OFF switch - Speed II
Key D = Motor ON/OFF switch - Speed III
Key E = Motor ON/OFF switch - Speed IV (intensive).
Filter alarm:
After 30 hours of operation, with the motor off, the speed keys (keys B, C, D and E) are on for 30 seconds to indicate
the grease filters need cleaning. After cleaning the grease filters, restart the hour counter (RESET) by pressing one of
the keys (B, C, D and E) during filter alarm.
After 120 hours of operation, with the motor off, the speed keys (keys B, C, D and E) flash for 30 seconds to indicate
the grease filters need cleaning and the charcoal filters replaced. Restart the hour counter (RESET) by pressing one of
the keys (B, C, D and E) during filter alarm.
Timer 5'; the timer can be started (switch-off delayed by 5 minutes) by pressing the keys B, C, or D for 2 seconds when
the motor is running; the selected speed key starts flashing.
Controls shown in Fig. 16:
Key A : Motor ON/OFF switch - Speed I
Key B : MOTOR / RESET FILTER ALARM. Increases and decreases the motor speed. When pressing the key (about
2 seconds) during display of the filter alarm (motor off) its reset the hour counter.
Key C : TIMER. When pressing the key when the motor is running, the TIMER is activated and the hood will automatically
be switched off after 5 minutes.
Key D : switches the lights on/off.
FILTER ALARM: After 30h of operation, all the LEDs are on. It indicates that the grease filters need to be cleaned.
After 120h of operation, all the LEDs are blinking; It indicates that the grease filters need to be cleaned and the charcoal
filters replaced.
After cleaning the grease filters (and/or replacing the charcoal filters), restart the hour counter (RESET) by pressing the
key B during display of the filter alarm.
Pay special attention to the grease filters; to remove the filter: push inward on the clamp at the handle andpull the filter
downward. Wash out the filter using a neutral soap.
If the model purchased has the controls shown in Figure 13/14:
the grease filter must be cleaned periodically: exactly how often depends on use (at leastonce every other month). If
the model purchased has the controls shown in Figure 15 and 16: see the Controls in Fig.15 / 16 (Filter alarm) in the
paragraph entitled “Operation”.
Charcoal filter/s: if using the hood in the filtering hood, the charcoal filter must be replaced periodically. To
remove the charcoal filters, proceed as follows, depending on the model purchased:
- if the hood features round charcoal filters (Fig. 17), remove the charcoal filter by turning counter-clockwise.
- if the hood features a panel type charcoal filter (Fig. 12), remove the charcoal filter by first of all removing
the two filter retainers M.
If the model purchased has the controls shown in Figure 13/14, the charcoal filters must be replaced according
to use: on the average once every 6 months. If the model purchased has the controls shown in Figure 15 and
16, see the Controls in Fig.15 / 16 (Filter alarm) in the paragraph entitled “Operation”.
Lighting:
- To replace the
incandescence bulbs, remove the fixture: apply a slight pressure on the 2 stops and at the
sametime push the fixture downwards (Fig.18).
- To change the halogen lamps shown in Fig. 19 open the cover levering from the proper slots. CAUTION: Do
not handle glass bulb with bare hands.
Replace it with lamps of the same type; if a lamp is not listed in the table shown in the “Warning” worksheet,
please contact the support center.
The motor used in this hood features a safety device (thermal cutout) that responds to temperature
changes For accidental reasons or due to installation faults, this device could engage and automatically
shut off the motor, thereby preventing serious damage to the equipment. In such cases, after allowing
the motor to cool down, the hood can be switched on again; the cause of the fault will nonetheless
have to be remedied, ensuring installation has been correctly made and that all the instructions in the
Information sheet have been complied with.
